IVO

Size Inch	Model No.	Resolution	Brightness	Top	Interface
4.3	M043GW32-R2	480 x 272	550	-30 - 85	8bits / TTL
5.0	M050SWN1-R2	480 x 234	585	-30 - 85	8bits/ TTL
7	M070AWPA-R0	800 x 480	1000	-30 - 85	8bits / TTL
	M070AWPA-R1	800 x 480	1000	-30 - 85	8bits / LVDS
8	M080AWP9-R0 / R2 / R6	800 x 480	750	-30 - 85	6 / 8bits / TTL
	M080AWP9-R4 / R7	800 x 480	600	-20 - 70	6 / 8bits / TTL
	M080AWP9-R1 / R3 / R5	800 x 480	1000	-30 - 85	8bits / TTL
	M080AWP4-R0 / R2	800 x 480	500	-30 - 85	6 / 8bits / TTL
	M080AWT8-R1	1024 x 600	670	-30 - 85	6bits + FRC / LVDS
8.88	M088AWFx-R0	1920 x 480	1000	-30 - 85	8bits / LVDS
9	M090AWP4-R0	800 x 480	750	-30 - 85	6bits / TTL
	M090AWP4-R1	800 x 480	750	-30 - 85	6bits / TTL
	M090SWT3-R1	1024 x 600	600	-20 - 70	6bits / LVDS
	M090SWT3-R2	1024 x 600	600	-20 - 70	6bits / LVDS
	M090AWA5-R0	1280 x 720	800	-30 - 85	8bits / TTL
	M090AWA6-R0 / R1	1280 x 720	1000	-30 - 85	8bits / LVDS
	M090AWA7-R0	1280 x 720	950	-30 - 85	8bits / LVDS
9.45	M123AW42 R3	1540 x 1540	1000	-30 - 85	8bits / LVDS
10.1	M101GWT9-R9	1024 x 600	450	-30 - 85	6bits / LVDS
	M101GWT9-RA	1024 x 600	800	-30 - 85	6bits / LVDS
	M101AWAx-R0	1280 x 720	1000	-30 - 85	8bits / LVDS
10.25	M102AWF2-R1 / R3	1920 x 720	1000	-30 - 85	8bits / LVDS
	M102AWF2-R1 / R2	1920 x 720	800	-30 - 85	8bits / LVDS
	M102AWFx-R0	1920 x 720	1000	-30 - 85	8bits
11.8	M118AW41-R0	1200 x 1600	750	-30 - 85	8bits / LVDS
12.3	M123AWF4-R0	1920 x 720	1000	-30 - 85	8bits
	M123AWF4-R1	1920 x 720	1000	-30 - 85	8bits
	M123AWF4-R3	1920 x 720	800	-30 - 85	8bits
	M123AWF2-R7	1920 x 720	1000	-30 - 85	8bits
12.8	M128AWF0-R0	1920 x 1080	1000	-30 - 85	8bits
25	M250AWKx-R0	3840 x 720	1000	-30 - 85	8bits / LVDS



＊other size please contact us !



---
